Wet batch concrete plant refers to the concrete batching plant that combines sand, raw aggregates, cement, and water together to form concrete ready for use. It is different from a dry concrete batching plant which just combines the sand, raw aggregates, cement together without water. The wet batching plant can produce high quality concrete with the adoption of JS series twin shaft concrete mixer, which has a strong mixing effect and high mixing efficiency.
It is widely used in large and medium-sized water conservancies, electric power, bridges, highways, and other projects with a large amount of concrete engineering, long construction period and concentrated construction sites.
Latest Cases
Aimix Wet Batch Concrete Plant For Sale
As an experienced China wet mix plant manufacturer, Aimix provides high-quality wet concrete batching plants for sale at a reasonable price.
The main types of Aimix wet concrete batch plants for sale include AJ25, AJ35, AJ50, AJ75. They are all skip hoist type concrete batching plants that adopt a skip hopper as the tool to transport raw aggregates. They all take JS series twin shaft concrete mixers as the main mixer. The main mixer of AJ25, AJ35, AJ50, AJ75 wet concrete plant is JS500, JS750, JS1000, JS1500.
| Model | Bucket type |
| AJ-25 | |
| Theoretical Productivity (m³/h) | 25 |
| Mixer Model (Mixer Output L) | JS500 |
| Rated Input Volume (Model of Batching Machine L) | 800 |
| Max.Aggregate Size (mm) | Φ60 |
| Standard Aggregate Bin Capacity (m³) | 3×3 |
| Powder Storage Silo (ton) (Optional) | 1×50 |
| Max. Discharging Height (m) | 3.8 |
| Model | Bucket type |
| AJ-35 | |
| Theoretical Productivity (m³/h) | 35 |
| Mixer Model (Mixer Output L) | JS750 |
| Rated Input Volume (Model of Batching Machine L) | 1200 |
| Max.Aggregate Size (mm) | Φ60 |
| Standard Aggregate Bin Capacity (m³) | 3×5 |
| Powder Storage Silo (ton) (Optional) | 2×50 |
| Max. Discharging Height (m) | 4.1 |
| Model | Bucket type |
| AJ-50 | |
| Theoretical Productivity (m³/h) | 50 |
| Mixer Model (Mixer Output L) | JS1000 |
| Rated Input Volume (Model of Batching Machine L) | 1600 |
| Max.Aggregate Size (mm) | Φ60 |
| Standard Aggregate Bin Capacity (m³) | 3×8 |
| Powder Storage Silo (ton) (Optional) | 1×100 |
| Max. Discharging Height (m) | 4.1 |
We also provide belt conveyor type wet concrete batch plants for sale such as AJ60, AJ90, AJ120, AJ180, AJ240. The difference is they all adopt a belt conveyor to transport the raw aggregates. Customers can choose either type according to their real needs. If you are not sure, it is better to ask our professional sales and engineers for advice.
| Model | AJ-60 |
| Capacity(m3/h) | 60 |
| Concrete mixer | JS500 |
| Mixer Power (kW) | 2 x 18.5 |
| Mixing Cycle Period (s) | 60 |
| Max.Aggregate Size (mm) | Φ60 |
| Max. Discharging Height (m) | 4.1 |
| Overall Weight (ton) | ≈40 |
| Installation Power (kW) | ≈110 |
| Model | AJ-90 |
| Capacity(m3/h) | 90 |
| Concrete mixer | JS1500 |
| Mixer Power (kW) | 2 x 30 |
| Mixing Cycle Period (s) | 60 |
| Max.Aggregate Size (mm) | Φ80 |
| Max. Discharging Height (m) | 4.1 |
| Overall Weight (ton) | ≈68 |
| Installation Power (kW) | ≈160 |
| Model | AJ-120 |
| Capacity(m3/h) | 120 |
| Concrete mixer | MAO3000/2000(SICOMA) |
| Mixer Power (kW) | 2×37 |
| Mixing Cycle Period (s) | 65 |
| Max.Aggregate Size (mm) | Φ80 |
| Max. Discharging Height (m) | 4.3 |
| Overall Weight (ton) | ≈93 |
| Installation Power (kW) | ≈220 |
| Model | AJ-180 |
| Capacity(m3/h) | 180 |
| Concrete mixer | MAO4500/3000(SICOMA) |
| Mixer Power (kW) | 2×55 |
| Mixing Cycle Period (s) | 65 |
| Max.Aggregate Size (mm) | Φ80 |
| Max. Discharging Height (m) | 4.3 |
| Overall Weight (ton) | ≈101 |
| Installation Power (kW) | ≈209 |
Aimix Wet Batch Concrete Plant Set up All Over the World
AIMIX Wet Batch Concrete Plant in Modular Type
The modular concrete batching plant integrates the modular concept in the design of the batching plant, which can not only reduce the floor cover space, but also facilitate the disassembly and assembly. It helps to reduce costs and increase working efficiency. Wet mix concrete batch plant in modular type is a good choice for emergency repair and constructions that need to be done in a short period. It saves time and helps to complete the construction work fastly.
Differences Between Wet Batch Concrete Plant And Dry Batch Concrete Plant
The main difference between wet batch concrete plant and dry batch concrete plant lies in three aspects: the configuration, the working principle, the application.
The configuration: wet mix concrete batch plant adopts the JS series twin shaft concrete mixer as the main mixer while the dry batch concrete plant has no concrete mixer.
The working principle: wet batching plant combines sand, raw aggregates, cement, and water together to form concrete ready for use.
Dry batch concrete plant just combines the sand, cement, and raw aggregates together and then transports the final mixture with a concrete mixer truck. Water will be added during the transportation of the concrete mixer truck.
The application: wet concrete batching plant has wide application since it can produce high quality concrete mixture. For example, bridges, highways, and airports etc.
Dry concrete batch plant is usually used in constructions that have lower requirements for concrete quality. For example, rural road construction.
Customer’s Feedback on Our Wet Mix Batching Plant
AIMIX Service Team in Indonesia
Aimix has exported our wet mix batching plants to many countries such as the Philippines, Pakistan, UK, Indonesia, Vietnam, Sri Lanka, Bangladesh etc. You can rely on us from pre-sale service to after-sale service.Besides, as a construction machinery manufacturer and exporter, Aimix has developed for more than 30 years. We have expanded our business to overseas countries in recent years.
- Professional engineer team, guarantee fast response and professional proposal.
- Branch office and team in Indonesia, quality and timely service assured.
- Local custom clearance partner in Major cities Surabaya and Jakarta and can solve custom clearance issues for customers who don’t have import experience.
- Spare parts are available in Indonesia.
- Indonesia’s local Installation team, with more than 10 years of installation experience, can guarantee timely installation and maintenance, even in Pandemic times.
Now, we not only have office in China, but also branch offices in overseas countries such as Indonesia, Pakistan, the Philippines, Sri Lanka, Uzbekistan. We have offices and sales in these areas to serve the local customers faster and better. That makes it very convenient for customers to buy construction equipment from us. Customers in these countries can get high quality wet concrete batching plants from us at a competitive price. Also, customers in these areas can get fast and reliable services from us from pre-sale to after-sale. We will do better and better in the future!
If you are interested in our wet batching plant and has any question, please don’t hesitate to contact us now! Leave a message in the form below, we will reply in 24 hours!
